¥204,019 JPY ¥231,000 JPY
| /
| Brand |
GANADOR
|
| Series Name |
GANADOR VERTEX 4WD SUV BLUE EXHAUST FOR TOYOTA HILUX GUN125 2GD-FTV 2,393CC DIESEL GDS-302BL
|
| Product Number |
GDS-302BL
|
| Compatible Car |
TOYOTA HILUX GUN125
|
| Compatible Engine |
2GD-FTV 2,393CC DIESEL
|
| Product Description |
Compatible Year Model: 2017/09-2020/08(2017/09-2020/08) <br> Model name: HILUX <br> Compatible grades: Z X <br> Compatible vehicle model: QDF-GUN125 <br> Drivetrain: 4WD <br> Engine model: 2GD-FTV 2,393CC DIESEL <br> Brand name: VERTEX 4WD SUV BLUE <br> Power: 148.1 ps (+10.5 ps vs. stock) <br> Proximity exhaust volume dB: 74 dB / 2,550 rpm <br> Muffler weight kg: 15.9 <br> Tail diameter: φ105×70 oval (quad side exit: 2 left + 2 right) * Tail section only made of titanium with blue anodising <br> Pipe diameter: φ70.0-60.5 <br> Attached parts: Hex bolt M12X35 (2) | Hex bolt M12X25 (2) | Flat washer M12 (12) | Flange nut M12 (2) | Hex bolt M10X35 (2) | Flat washer M10 (2) | Flange nut M10 (2) | Bolt with washer M8X35 & flange nut M8 set (3) | Gasket G21 (1 pc) | Gasket G01 (1) | Gasket GR05 (1) | Spare tyre bracket (1) | Supplied bracket (1 each L & R) | Supplied rubber for φ12 (2) | Clearance gauge (1) | Instruction manual <br> Genuine reused parts: Rubber mount (3) <br> Special notes: Cannot be fitted to the post-facelift "3DF-GUN125" (R2.8-); the separate part number "GDS-302C series" applies. The spare tyre is offset using the supplied spare tyre bracket. Fitment with aero parts has not been verified. Wool-less silencer. The blue-anodised sections vary from unit to unit. Do not use abrasive cleaners.
|
| Remarks |
Z X. Cannot be fitted to the post-facelift "3DF-GUN125" (R2.8-); the separate part number "GDS-302C series" applies. The spare tyre is offset using the supplied spare tyre bracket. Fitment with aero parts has not been verified. Wool-less silencer. The blue-anodised sections vary from unit to unit. Do not use abrasive cleaners.
|
| Notes |
Images are for illustration purpose only. Actual product may vary.
|
