RSE FORGED PISTON KIT 87.00MM CH29.50 (3.6) CP FOR TOYOTA 2JZ-GTE RA202A-TY03BP

RSE FORGED PISTON KIT 87.00MM CH29.50 (3.6) CP FOR TOYOTA 2JZ-GTE RA202A-TY03BP

¥174,874 JPY ¥198,000 JPY

| /

 More payment options
Brand
RSE
Series Name
FORGED PISTON KIT 87.00MM CH29.50 (3.6) CP
Product Number
RA202A-TY03BP
Compatible Car
TOYOTA
Compatible Engine
2JZ-GTE
Product Description
Bore diameter (mm) 87.00 (genuine +1.0) Pin diameter (mm) 22.0 Pin length (mm) 64.0 Circlip inner diameter (mm) 22.0 Valve recess Yes Compression height (mm) 29.50 (genuine -4.5) Crown volume (cc) - 22.6 Piston weight (g) 319.0 Pin weight (g) 133.0 Total weight (g) 452.0 Top ring (mm) 1.20 x 2.90 Second ring (mm) 1.20 x 3.00 Oil ring (mm) 2.00 x 2.70 Material A2618
Notes
Images are for illustration purpose only. Actual product may vary.
