FUJITSUBO A-R EXHAUST FOR TOYOTA GR YARIS GXPA16 KOUKI 570-21238

FUJITSUBO

A-R EXHAUST

570-21238

TOYOTA GR YARIS GXPA16 KOUKI

Body model: 4BA-GXPA16
Engine model: G16E-GTS
Model year: R6.4~ (2024.4~)
Tailtip Style: φ101.6 slash (12°・RL) BG (baked color gradation) color tail can be changed (additional charge)
Pipe Diameter: φ70.0-φ50.8
Fitting Parts: •Slit clamp installation kit SLIT-HC70×1
•M8 plate washer (small)×4
•M8×15mm bolt×4
•M8 spring washer×4
•080-37501 plate gasket×1 【Click here to purchase for repair】
•080-35001 plate gasket×2 【Click here to purchase for repair】
•M10×35mm Flange bolts x 6
•M10 flange nuts x 8
•Special bracket (R) x 1
•Special bracket (L) x 1
•M10 plate washers x 2
•M10×70mm 26S bolts x 2
•M10 nuts x 2
Acceleration: Standard (STD): 397.9N・m (40.6kg・m)/4077rpm FUJITSUBO: 403.8N・m (41.2kg・m)/4093rpm
Peak Power: Standard (STD): -kg FUJITSUBO: 18.1kg
Peak Torque: Standard (STD): 62dB FUJITSUBO: 64dB
Weight: Standard (STD): 78dB FUJITSUBO: 79dB
Idling Exhaust Noise: Standard (STD): 70dB FUJITSUBO: 73dB
Proximity Exhaust Noise: Standard (STD): 76dB FUJITSUBO: 77dB
2000RPM Exhaust Noise: Standard (STD): 82dB FUJITSUBO: 83dB

For both AT and MT vehicles *Cannot be installed on RC grade vehicles equipped with constant speed rear differential

Images are for illustration purpose only. Actual product may vary.
